In this post we will show why Gridcoin is insecure and probably will never achieve better security. Therefore, we are going to explain two critical implementation vulnerabilities and our experience with the core developer in the process of the responsible disclosure.
In our last blog post we described the Gridcoin architecture and the design vulnerability we found and fixed (
). Now we come to the process of responsibly disclosing our findings and try to fix the two implementation vulnerabilities (
The whole Gridcoin currency is seriously insecure against attacks and should not be trusted anymore; unless some developers are in place, which have a profound background in protocol and application security.
Currently there are 2 implementation vulnerabilities in the source code, and we can mount the following attacks against Gridcoin:
- We can steal the block creation reward from many Gridcoin minters
- We can efficiently prevent many Gridcoin minters from claiming their block creation reward (DoS attack)
So why do we not just open up an
issue online explaining the problems?
Because we already fixed a critical design issue in Gridcoin last year and tried to help them to fix the new issues. Unfortunately, they do not seem to have an interest in securing Gridcoin and thus leave us no other choice than fully disclosing the findings.
In order to explain the vulnerabilities we will take a look at the current Gridcoin source code (version
3.5.9.8).
WARNING: Due to the high number of source code lines in the source files, it can take a while until your browser shows the right line.
Stealing the BOINC block reward
The developer implemented our countermeasures in order to prevent our attack from the last blog post. Unfortunately, they did not look at their implementation from an attacker's perspective. Otherwise, they would have found out that they conduct not check, if the signature over the last block hash really is done over the last block hash. But we come to that in a minute. First lets take a look at the code flow:
 |
| In the figure the called-by-graph can be seen for the function VerifyCPIDSignature. |
- CheckBlock → DeserializeBoincBlock [Source]
- Here we deserialize the BOINC data structure from the first transaction
- CheckBlock → IsCPIDValidv2 [Source]
- Then we call a function to verify the CPID used in the block. Due to the massive changes over the last years, there are 3 possible verify functions. We are interested in the last one (VerifyCPIDSignature), for the reason that it is the current verification function.
- IsCPIDValidv2 → VerifyCPIDSignature [Source]
- VerifyCPIDSignature → CheckMessageSignature [Source, Source]
In the last function the real signature verification is conducted [
Source]. When we closely take a look at the function parameter, we see the message (
std::string sMsg) and the signature (
std::string sSig) variables, which are checked. But where does this values come from?
If we go backwards in the function call graph we see that in
VerifyCPIDSignature the
sMsg is the string
sConcatMessage, which is a concatenation of the s
CPID and the
sBlockHash.
We are interested where the
sBlockHash value comes from, due to the fact that this one is the only changing value in the signature generation.
When we go backwards, we see that the value originate from the deserialization of the BOINC structure (
MiningCPID& mc) and is the variable
mc.lastblockhash [
Source,
Source]. But wait a second, is this value ever checked whether it contains the real last block hash?
No, it is not....
So they just look if the stored values there end up in a valid signature.
Thus, we just need to wait for one valid block from a researcher and copy the signature, the last block hash value, the CPID and adjust every other dynamic value, like the
RAC. Consequently, we are able to claim the reward of other BOINC users. This simple bug allows us again to steal the reward of every Gridcoin researcher, like there was never a countermeasure.
Lock out Gridcoin researcherThe following vulnerability allows an attacker under specific circumstances to register a key pair for a CPID, even if the CPID was previously tied to another key pair. Thus, the attacker locks out a legit researcher and prevent him from claiming BOINC reward in his minted blocks.
Reminder: A beacon is valid for 5 months, afterwards a new beacon must be sent with the same public key and CPID.
Therefore, we need to take a look at the functions, which process the beacon information. Every time there is a block, which contains beacon information, it is processed the following way (click image for higher resolution):
 |
In the figure the called-by-graph can be seen for the function GetBeaconPublicKey. |
We now show the source code path:
- ProcessBlock → CheckBlock [Source]
- CheckBlock → LoadAdminMessages [Source]
- LoadAdminMessages → MemorizeMessages [Source]
- MemorizeMessages → GetBeaconPublicKey [Source]
In the last function
GetBeaconPublicKey there are different paths to process a beacon depending on the public key, the CPID, and the time since both were associated to each other.
For the following explanation we assume that we have an existing association (bound) between a CPID
A and a public key
pubK_A for 4 months.
- First public key for a CPID received [Source]
- The initial situation, when pubK_A was sent and bind to CPID A (4 months ago)
- Existing public key for a CPID was sent [Source]
- The case that pubK_A was resent for a CPID A, before the 5 months are passed by
- Other public key for a CPID was sent [Source]
- The case, if a different public key pubK_B for the CPID A was sent via beacon.
- The existing public key for the CPID is expired
- After 5 months a refresh for the association between A and pubK_A is required.
When an incoming beacon is processed, a look up is made, if there already exists a public key for the CPID used in the beacon. If yes, it is compared to the public key used in the beacon (case 2 and 3).
If no public key exists (case 1) the new public key is bound to the CPID.
If a public key exists, but it was not refreshed directly 12.960.000 seconds (5 months [
Source]) after the last beacon advertisement of the public key and CPID, it is handled as no public key would exist [
Source].
Thus, case 1 and 4 are treated identical, if the public key is expired, allowing an attacker to register his public key for an arbitrary CPID with expired public key. In practice this allows an attacker to lock out a Gridcoin user from the minting process of new blocks and further allows the attacker to claim reward for BOINC work he never did.
There is a countermeasure, which allows a user to delete his last beacon (identified by the CPID) . Therefore, the user sends 1 GRC to a special address (
SAuJGrxn724SVmpYNxb8gsi3tDgnFhTES9) from an GRC address associated to this CPID [
Source]. We did not look into this mechanism in more detail, because it only can be used to remove our attack beacon, but does not prevent the attack.
The responsible disclosure process
As part of our work as researchers we all have had the pleasure to responsible disclose the findings to developer or companies.
For the reasons that we wanted to give the developer some time to fix the design vulnerabilities, described in the last blog post, we did not issue a ticket at the
Gridcoin Github project. Instead we contacted the developer at September the 14th 2016 via email and got a response one day later (2016/09/15). They proposed a variation of our countermeasure and dropped the signature in the advertising beacon, which would result in further security issues. We sent another email (2016/09/15) explained to them, why it is not wise to change our countermeasures and drop the signature in the advertising beacon.
Unfortunately, we did not receive a response. We tried it again on October the 31th 2016. They again did not respond, but we saw in the source code that they made some promising changes. Due to some other projects we did not look into the code until May 2017. At this point we found the two implementation vulnerabilities. We contacted the developer twice via email (5th and 16th of May 2017) again, but never received a response. Thus, we decided to wait for the WOOT notification to pass by and then fully disclose the findings. We thus have no other choice then to say that:
The whole Gridcoin cryptocurrency is seriously insecure against attacks and should not be trusted anymore; unless some developers are in place, which have a profound background in protocol and application security.
